Mechanical Properties Per DIN 267 Part 4 (Internally Threaded Fasteners) Proof Stress Core Hardness Rockwell MPa (max.) Class 10 Medium carbon steel; quenched. Mechanical Properties of Metric Stainless Steel Per ISO 3506-1 Nuts MPa MPa MPa 50 (soft). D EUTSCHE NORM June 2004 DIN EN ISO 4762 ICS 21.060.10 Supersedes February 1998 edition. Hexagon socket head cap screws (ISO 4762: 2004) English version of DIN EN ISO 4762 Zylinderschrauben mit Innensechskant (ISO 4762: 2004) European Standard EN ISO 4762: 2004 has the status of a DIN Standard. A comma is used as the decimal marker.

Socket Cap Screws

Iso 4762 2004

A2 / A4 Stainless

S015 – 912-A2

S016 – 912-A4

Iso 4762 Bolt

Diameter d₁	M2		M2.5		M3		M4		M5		M6		M8
t min.	1		1.1		1.3		2		2.5		3		4
s	1.5		2		2.5		3		4		5		6
k max.	2		2.5		3		4		5		6		8
d₂	3.8		4.5		5.5		7		8.5		10		13
Length (mm)	A2	A4	A2	A4	A2	A4	A2	A4	A2	A4	A2	A4	A2	A4
Length (mm)	S015	S016	S015	S016	S015	S016	S015	S016	S015	S016	S015	S016	S015	S016
3	100
4	100	100	100
5	100	100	100
6	100	100	100	100	100	100	100	100
8	100	100	100	100	100	100	100	100	100
10	100	100	100	100	100	100	100	100	100	100	100
12	100	100	100	100	100	100	100	100	100	100	100	100
14	100	100	100	100
16	100	100	100	100	100	100	100	100	100	100	100	100
18	100	100	100
20	100	100	100	100	100	100	100	100	100	100
25	100	100	100	100	100	100	100	100	100	100
30	100	100	100	100	100	100	100	100	100	100
35	100	100	100	100	100	100	100	100	100	100
40	100	100	100	100	100	100	100	100	100
45	100	100	100	100	100	100	100	100	100
50	100	100	100	100	100	100	100	100
55	100	100	100	100	100	100	100
60	100	100	100	100	100	100	100	100
65	100	100
70	100	100	100	100	100	100
75	100
80	100	100	100	100	100
85	100
90	100	100	100	100	100
100	100	100	100	100	100
110	100	100
120	100	100	100
130	100
140	100	100
160	100
Order Number -> 912-A2 M2.5×4 = S015-2.5-0004 912-A4 M8x120 = S016-008-0120

Diameter d₁	M10		M12		M14		M16		M20		M24
t min.	5		6		7		8		10		12
s	8		10		12		14		17		19
k max.	10		12		14		16		20		24
d₂	16		18		21		24		30		36
Length (mm)	A2	A4	A2	A4	A2	A4	A2	A4	A2	A4	A2	A4
Length (mm)	S015	S016	S015	S016	S015	S016	S015	S016	S015	S016	S015	S016
16	100	100
20	100	100	50	50	25
25	100	100	50	50	25	25
30	100	100	50	50	50	25	25
35	100	100	50	50	25	25
40	100	100	50	50	50	50	25	25	25	25
45	50	50	50	50	25	25	25
50	50	50	50	50	50	50	25	25	25	25
55	50	50	50	50	25	25	25
60	50	50	50	50	25	25	25	25	25	25	10
65	50	25
70	50	50	25	25	25	25	25	25	25	25
75	25
80	50	50	25	25	25	25	25	25	25	25	10
90	50	50	25	25	25	25	25	25	25	10
100	50	50	25	25	25	25	25	25	25	25	10
110	50	50	25	25	25	25
120	50	50	25	25	25	25	25	25	10
140	50	25	10	10	10	10
150	10	10
160	25	1	10	10
180	10
Order Number -> 912-A2 M10x20 = S015-010-0020 912-A4 M24x160 = S016-024-0160
